Philips
model 495X
General
features
|
Radio type |
Mains powered table radio |
|
Circuit type |
Superheterodyne, 452kHz IF with
delayed AVC |
|
Dimensions |
580x330x250mm, 11.6kg |
|
Cabinet |
2-tone lacquered veneered wood,
cloth grille, metal decoration, printed glass dial in Bakelite bezel. |
|
Loudspeaker |
200mm, moving coil, permanent
magnet |
|
Main controls |
Tone, Volume/on-off, tuning and
waveband switch |
|
Extra controls |
PU switch, local/remote switch |
|
Connections |
Antenna, ground, gramophone,
external loudspeaker |
|
Power |
AC, 110-245V in 6 steps, 55W |
Wave
bands
|
LW |
708-2000m |
|
MW |
160-585m |
|
SW |
46-160m |
|
SW |
13.5-46m |
Circuits
and Tubes
|
RF preamplifier |
EF8 low noise remote cutoff
pentode |
|
Oscillator and mixer |
ECH3 triode-hexode |
|
IF amplifier, detector and AVC |
EBF2 duodiode- remote cutoff
pentode |
|
Audio amplifier |
EF9 remote cutoff pentode |
|
Audio power amplifier |
EL3 9W pentode |
|
Rectifier |
AZ1 dual power diode |
|
Tuning indicator |
EM4 dual sensitivity fluorescent
tube-triode |
