Radio type

Early mains powered table radio with integral loudspeaker.

Circuit type

2 stage tuned radio frequency, 2 tuned circuits

Dimensions

Cabinet

'Arbolite',Bakelite and steel, with cloth grille in Bakelite bezel

Loudspeaker

200mm, moving iron, permanent magnet

Main controls

Tuning, reaction, grid bias (volume), waveband switch, power

Extra controls

Connections

Antenna, ground, PU, extra loudspeaker

Power

AC, 103-253V in several steps

Lower band

950-400m

Higher band

400-250m

RF amplifier 1

E452 sharp cutoff tetrode

RF amplifier 2

E452 sharp cutoff tetrode

Audio preamplifier

E424N triode

Audio power amplifier

C443 directly heated pentode

Rectifier

506 directly heated power dual diode
